How to Install the DENZA B8 Passenger Screen
Step-by-step installation reference for the Roadnavier 12.3-inch passenger entertainment display for DENZA B8 / Leopard 8, including dashboard removal, harness connection, mounting and post-installation checks.
Before You Start
This guide documents the installation route used for the Roadnavier DENZA B8 passenger-screen system. Vehicle configuration and production version should be confirmed before installation, especially for right-hand-drive vehicles.
What the Factory Dashboard Looks Like
The passenger display replaces the relevant passenger-side dashboard trim area while the original DENZA center infotainment display remains in the vehicle.
DENZA B8 passenger-side dashboard before installation.
Dashboard area after trim removal, showing the mounting area and vehicle connectors.
Step-by-Step Installation
Remove the Factory Center Display
Use a plastic trim-removal tool to carefully release the trim surrounding the original center display. Remove the relevant fixing bolts, then carefully pull the factory display forward.
- Disconnect the required factory harness connectors.
- Disconnect the LVDS connection carefully.
- Place the original display somewhere protected.
Remove the Passenger-Side Trim
Starting from an accessible edge, use the plastic trim tool to release the passenger-side decorative panel. Work gradually around the panel rather than pulling from one point.
Rear of the removed factory passenger trim panel.
Remove the Mounting Screws
With the decorative panel removed, locate the four mounting screws in the passenger-side mounting area. Remove the screws and retain them for installation of the replacement assembly.
Connect the Passenger-Screen Harness
Connect the Roadnavier passenger-screen harness to the matching vehicle connectors according to the supplied harness configuration. Do not force a connector if its shape or locking position does not match.
Route the passenger-screen power connection toward the specified fuse-box area according to the supplied installation configuration.
Connection Overview
Passenger Display → Roadnavier Harness → Matching Vehicle Connectors
Power Connection → Specified Fuse-Box / ACC Power Location
Connector layout may vary with the final vehicle-specific harness. Always follow the harness supplied with your unit.
Mount the New Passenger Display
Arrange the harness so that no cable is pinched behind the screen. Align the passenger-display assembly with the dashboard mounting points and secure it using the required mounting screws.
- Check that the housing sits evenly against the dashboard.
- Confirm cables are not trapped behind mounting points.
- Do not fully close all trim until the system has been tested.
Reconnect the Factory Center Display
Reconnect the factory center-screen harnesses and LVDS connection. Reinstall the original center display and its mounting hardware.
Power On and Test Before Final Assembly
Start the vehicle and test the passenger display before pressing all dashboard trim completely back into position.
Passenger screen starts correctly.
Touchscreen responds normally.
Original center screen operates normally.
No unexpected warnings appear.
Test Wi-Fi / Bluetooth as applicable.
Housing sits evenly with no trapped cables.
Complete the Installation
Once all functions have been checked, switch the vehicle off, secure any loose wiring, reinstall the remaining trim pieces and confirm that all clips are fully seated.
Video Reference
Watch the product video before installation to become familiar with the display, connectors and mounting structure.
After Installation
Before returning the vehicle to normal use, verify both the new passenger display and the original DENZA systems.
Passenger display powers on/off correctly.
Factory center display functions normally.
No abnormal dashboard warnings.
All trim panels are securely seated.
No cables are visible, loose or pinched.
Passenger-display audio/connectivity tested.
Common Installation Questions
Does the original DENZA center screen get replaced?
No. The passenger display is an additional screen. The original center infotainment display is removed temporarily during installation where required and then reinstalled.
Do I need to cut the vehicle wiring?
The Roadnavier system uses a vehicle-specific harness. Follow the connector and power-routing instructions supplied with the production unit. Do not cut factory wiring unless specifically instructed for your confirmed configuration.
Can I return the dashboard to its original configuration?
The installation is designed around replaceable trim and vehicle-specific mounting components. Keep all original parts and screws if you may want to restore the original dashboard later.
Does this guide apply to Australian RHD DENZA B8 vehicles?
The RHD version is currently subject to production confirmation. Roadnavier has participated in collecting vehicle and mould data for the RHD development, but final production fitment should be confirmed before ordering or installation.
What should I do if a connector does not match?
Stop installation and do not force the connector. Take clear photos of the vehicle connector, supplied harness and dashboard configuration and contact Roadnavier for compatibility verification.
What if the passenger screen does not power on?
Before removing the unit, check the passenger-screen harness, power connection and connector locking positions. If the issue remains, send Roadnavier photos or a short video showing the connections and power-on behaviour.
