How to Identify Your Nissan Murano Z51 Factory Head Unit & Wiring Configuration
Nissan Murano Z51 vehicles use different factory dashboard and head unit configurations. This guide explains the differences and shows which Roadnavier configuration corresponds to each original setup.
For ordering, the choice is simple:
Low Trim → select “Low Trim”
Standard Trim or High Trim → select “Standard / High Trim”
Type 1 / Type 2 / Type 3 identification is only used to understand the factory head unit and wiring configuration. It is not an additional product option you need to select.
Compare Your Original Dashboard
The easiest first step is to compare the original center dashboard with the examples below.
Low Trim → Low Trim
Standard / High Trim → Standard / High Trim
Low Trim vs. High Trim
Original Factory Head Unit Retained
Original Factory Head Unit Removed
Both Configurations Use the Same Factory-Style Android Screen
The internal installation path is different, but the finished dashboard keeps the same integrated Roadnavier screen design.
Why the Wiring Is Different
Low Trim and Standard / High Trim vehicles use different factory connections. The Roadnavier wiring configuration therefore matches the Factory Configuration selected on the product page.
Why High Trim Has Type 1 / Type 2 / Type 3
High Trim Murano Z51 vehicles can use three different original factory head units. They may look similar from the front, but their rear connections are different.
Roadnavier refers to these as Type 1, Type 2 and Type 3. This classification is mainly used for wiring and technical support.
Factory Head Unit Type 1
Uses the Type 1 factory head unit and corresponding wiring configuration.
Factory Head Unit Type 2
Uses the Type 2 factory head unit and corresponding wiring configuration.
Factory Head Unit Type 3
Uses the Type 3 factory head unit and corresponding wiring configuration.
What You Actually Need to Choose
Nissan Murano Z51 Configuration Questions
What is the main difference between Low Trim and High Trim?
Low Trim retains the original factory head unit. High Trim removes the original factory head unit.
Which Factory Configuration should I select?
Select Low Trim for a Low Trim vehicle. Select Standard / High Trim for a Standard Trim or High Trim vehicle.
Do I need to choose Type 1, Type 2 or Type 3 when ordering?
No. Type 1 / Type 2 / Type 3 describes the original High Trim factory head unit and is mainly used for wiring identification and technical support.
Why are there different wiring harnesses?
Different Murano Z51 factory configurations use different original connections. The supplied wiring therefore depends on the Factory Configuration selected for the vehicle.
